MPN-RCM8/M10 - 晟江工业品

InstallationSystems > PipeRings > MPN-RCM8/M10

MPN-RCM8/M10

已选总价:￥0.00
已选数量:0件

所有费用均已包含增值税，不含运费。运费详情请参阅运费指导书。

产品详情与编号

序号	产品编号	名称	Packaging unit	Thread - M	Clamping range - D	售价
	全部	全部	全部	全部	全部
1.0	335706	Comfort pipe ring MPN-RC 160 B	Packaging unit 10 pc	Thread - M M8. M10	Clamping range - D 157 - 163 mm	￥6305.00
2.0	335688	Comfort pipe ring MPN-RC 21/2" B	Packaging unit 10 pc	Thread - M M8. M10	Clamping range - D 72 - 77 mm	￥4050.00
3.0	335700	Comfort pipe ring MPN-RC 125 B	Packaging unit 10 pc	Thread - M M8. M10	Clamping range - D 123 - 128 mm	￥5295.00
4.0	335683	Comfort pipe ring MPN-RC 2" A	Packaging unit 10 pc	Thread - M M8. M10	Clamping range - D 57 - 61 mm	￥3255.00
5.0	335680	Comfort pipe ring MPN-RC 1 1/4" A	Packaging unit 25 pc	Thread - M M8. M10	Clamping range - D 42 - 46 mm	￥2644.80
6.0	335673	Comfort pipe ring MPN-RC 1/4" A	Packaging unit 25 pc	Thread - M M8. M10	Clamping range - D 12 - 16 mm	￥1910.00
7.0	335674	Comfort pipe ring MPN-RC 3/8" A	Packaging unit 25 pc	Thread - M M8. M10	Clamping range - D 17 - 20 mm	￥2064.80
8.0	335676	Comfort pipe ring MPN-RC 3/4" A	Packaging unit 25 pc	Thread - M M8. M10	Clamping range - D 25 - 28 mm	￥2315.20
9.0	335682	Comfort pipe ring MPN-RC 52/56 A	Packaging unit 25 pc	Thread - M M8. M10	Clamping range - D 52 - 56 mm	￥3080.00
10.0	335696	Comfort pipe ring MPN-RC 110 B	Packaging unit 10 pc	Thread - M M8. M10	Clamping range - D 108 - 112 mm	￥4785.00
11.0	335704	Comfort pipe ring MPN-RC 5" B	Packaging unit 10 pc	Thread - M M8. M10	Clamping range - D 138 - 144 mm	￥5505.00
12.0	335675	Comfort pipe ring MPN-RC 1/2" A	Packaging unit 25 pc	Thread - M M8. M10	Clamping range - D 21 - 24 mm	￥2170.00
13.0	335677	Comfort pipe ring MPN-RC 29/32 A	Packaging unit 25 pc	Thread - M M8. M10	Clamping range - D 29 - 32 mm	￥2360.00
14.0	335690	Comfort pipe ring MPN-RC 78/84 B	Packaging unit 10 pc	Thread - M M8. M10	Clamping range - D 78 - 84 mm	￥4140.00
15.0	335684	Comfort pipe ring MPN-RC 60/66 A	Packaging unit 10 pc	Thread - M M8. M10	Clamping range - D 60 - 66 mm	￥3495.00
16.0	335692	Comfort pipe ring MPN-RC 3" B	Packaging unit 10 pc	Thread - M M8. M10	Clamping range - D 87 - 93 mm	￥4290.00
17.0	335698	Comfort pipe ring MPN-RC 4" B	Packaging unit 10 pc	Thread - M M8. M10	Clamping range - D 114 - 118 mm	￥4870.00
18.0	335678	Comfort pipe ring MPN-RC 1" A	Packaging unit 25 pc	Thread - M M8. M10	Clamping range - D 33 - 37 mm	￥2435.20
19.0	335686	Comfort pipe ring MPN-RC 67/71 A	Packaging unit 10 pc	Thread - M M8. M10	Clamping range - D 67 - 71 mm	￥3740.00
20.0	335672	Comfort pipe ring MPN-RC 8/11 A	Packaging unit 25 pc	Thread - M M8. M10	Clamping range - D 8 - 11 mm	￥1850.00
21.0	335702	Comfort pipe ring MPN-RC 133 B	Packaging unit 10 pc	Thread - M M8. M10	Clamping range - D 131 - 137 mm	￥5380.00
22.0	335681	Comfort pipe ring MPN-RC 1 1/2" A	Packaging unit 25 pc	Thread - M M8. M10	Clamping range - D 47 - 51 mm	￥2970.00
23.0	335708	Comfort pipe ring MPN-RC 6" B	Packaging unit 10 pc	Thread - M M8. M10	Clamping range - D 164 - 170 mm	￥6705.00
24.0	335679	Comfort pipe ring MPN-RC 37/41 A	Packaging unit 25 pc	Thread - M M8. M10	Clamping range - D 37 - 41 mm	￥2555.20
25.0	335694	Comfort pipe ring MPN-RC 101,6 B	Packaging unit 10 pc	Thread - M M8. M10	Clamping range - D 99 - 104 mm	￥4625.00

注：本公司对上述参数保有最终解释权，如若变动，恕不通知。

MPN-RC M8/M10 NEW MPN-RC M8/M10 NEW Thread - M: M8, M10 Material composition: DD11 - DIN EN 10111 Temperature resistance: -40-110 °C Features & Applications Features Click-type catch for quick, easy, secure closure Three-stage safety closure allows easier installation, especially overhead Clamping screw with combination cross-recess in head and hexagon head Screw is secured against loss Preclamping Applications Medium-duty pipe installations up to 6" Fastening drinking water pipes and heating pipes in residential and industrial construction Pipe rings for use in dry interiors only For approval or certificate information, please see individual items.

Technical Data

Thread - M: M8, M10
Material composition: DD11 - DIN EN 10111
Temperature resistance: -40 - 110 °C
Surface finish: Galvanized
Insulation material: EPDM rubber
Hardness insulation material: 50° ±5° Shore A
Noise reduction: 15 dB (A)
Approvals: Fire class B2

Documents

Approval document
- PDF Building material class B2, German, [ 14.6 kB ]
