CONTI® 混凝土管是一款用于混凝土与固体输送泵完美的软管。软管内衬由特殊胶料挤出成型，光滑，高耐磨；增强层由高强度织物编织加强，以满足施工现场的最高要求。相比钢丝增强软管，质轻，易操作。
工作压力：85巴
爆破压力：170巴
温度范围：-40℃~+90℃
内衬 ：黑色光滑挤压内衬，高耐磨性（根据DIN ISO 4649-A：＜60mm³）
外胶 ：黑色布纹外胶层，耐臭氧，耐气候，UV及耐磨损
加强层：最少四层合成纺织纱线加强
软管外侧标识：3条橙色条纹及 "Continental ContiTech CONCRETE STAR TEXTILE DN 75 PN 85 BAR / 1233 PSI SF2 Made in Germany" 轴向标记于黑色表面
Marking:3 orange, axially applied stripes on black cover “Continental ContiTech CONCRETE STAR TEXTILE DN 75 PN 85 BAR / 1233 PSI SF2 Made in Germany”
CONTI® CONCRETE STAR TEXTILE is the perfect hose for the use in concrete and soild pumps. With its extruded smooth bore tube, made of highly abrasion resistant special compound and the high tension textile reinforcement, the hose is designed to meet the strongest requirements at construction site. Significant weight savings compared to hoses with steel wire reinforcement. Made in Germany!
Black, smooth, extruded lining, highly resistant to abrasion (acc. to DIN ISO 4649-A: <60mm³)
Min. 4 layer reinforcement, made of synthetic textile yarn
Black, fabric patterned cover, resistant to ozone, weather, UV and abrasion
Working pressure up to 85 bar / 1233 psi
Temperature range from -40°C up to +90°C / -40°F up to +194°F
Fixed lengths with built-in couplings acc. to customers request
Couplings are partly hardend and with galvanized sleeve
Available flange systems: Victaulic, Heavy Duty (US), etc.
| 内径毫米 |
壁厚毫米 |
外径毫米 |
公称压力 巴/20°C |
重量 千克/米 |
长度 米 |
产品编号 |
| 50 |
10.0 |
70 |
85 |
2.300 |
40 |
0117 131801 |
| 65 |
10.0 |
85 |
85 |
2.750 |
40 |
0117 131802 |
| 75 |
11.0 |
97 |
85 |
3.450 |
40 |
0117 131803 |
| 80 |
12.0 |
104 |
85 |
4.000 |
40 |
0117 131804 |
| 100 |
14.0 |
128 |
85 |
5.950 |
40 |
0117 131805 |
| 125 |
14.0 |
153 |
85 |
7.800 |
40 |
0117 131806 |
