红色TRIX® -乙炔管用于安全输送燃气。软管符合最新的DIN EN ISO 3821标准，提供最高的安全保障。软管非常柔软，耐用，耐臭氧及耐气候，表面光滑防尘。优秀的软管品质使其数十年广泛应用于各工程公司，铸造厂，船厂，钢铁厂，汽车厂及地下隧道施工等行业。
工作压力：20巴
爆破压力：60巴
温度范围：-40℃~+60℃
内衬 ：黑色光滑EPDM内衬
外胶 ：红色光滑EPDM外胶层，耐臭氧，耐气候，UV及耐磨损
加强层：合成纤维
不含脱芯剂，不含任何有害喷涂物质
内衬抗静电，R＜10 6Ω/m
符合 DIN EN ISO 3821要求
软管外侧标识："Continental ContiTech TRIX® AUTOGEN DN 9 DIN EN ISO 3821 2MPa (20 BAR / 290 PSI) Made in Germany" 轴向标记于红色表面
Marking:“Continental ContiTech TRIX® AUTOGEN DN 9 DIN EN ISO 3821 2MPa(20 BAR / 290 PSI) Made in Germany” on red cover
The TRIX® Acetylene hose red is designed for the transport of acetylene gases. It meets the latest regulations of the DIN EN ISO 3821 standard and thus offers the highest possible safety. The hose is extremely robust,flexible, resistant to ozone and weather and has a smooth, dirt-proof cover.The excellent quality is the reason, why the hose is most popular and is being used for decades in installation and heating system companies,foundries, shipyards, for the construction of bridges, in the steel and car body construction, over- and underground workings, in welding shops and at manufacturers of welding apparatus.
Black, non-porous and smooth EPDM lining
Reinforcements: synthetic fibres
Red, smooth EPDM-cover, resistant to ozone, weather, UV and abrasion
Working pressure up to 20 bar / 290 psi
Temperature range from -40°C up to +60°C / -40°F up to +140°F
Highly flexible, robust
Non-buckling, dimensionally stable
Release agent- and fat-free, free from any product harmful to lacquer
Lining electrically conductive, R < 106 Ω/m
According to DIN EN ISO 3821
| 内径毫米 |
壁厚毫米 |
外径毫米 |
公称压力 巴/20°C |
重量 千克/米 |
长度 米 |
产品编号 |
| 4 |
3.5 |
11 |
20 |
0.130 |
40 |
0119 111701 |
| 6.3 |
3.5 |
13.3 |
20 |
0.170 |
40 |
0119 111702 |
| 9 |
3.5 |
16 |
20 |
0.210 |
40 |
0119 111703 |
| 11 |
3.5 |
18 |
20 |
0.250 |
40 |
0119 111704 |
| 12.5 |
4.5 |
21.5 |
20 |
0.370 |
40 |
0119 111705 |
| 16 |
4.5 |
25 |
20 |
0.430 |
40 |
0119 111706 |
